AD8232 . Single Lead Heart Rate Monitor Front End







AD8232

Fully integrated single-lead ECG front end

Low supply current: 170 µA (typical)

Common-mode rejection ratio: 80 dB (dc to 60 Hz)

Two or three electrode configurations High signal gain (G = 100) with dc blocking capabilities

2-pole adjustable high-pass filter Accepts up to ±300 mV of half cell potential

Fast restore feature improves filter settling Uncommitted op amp

3-pole adjustable low-pass filter with adjustable gain

Leads off detection: ac or dc options Integrated right leg drive (RLD) amplifier

Single-supply operation: 2.0 V to 3.5 V

Integrated reference buffer generates virtual ground Rail-to-rail output

Internal RFI filter 8 kV HBM ESD rating Shutdown pin

20-lead, 4 mm × 4 mm LFCSP and LFCSP_SS package Qualified for automotive applications







데이터 시트 : https://www.analog.com/media/en/technical-documentation/data-sheets/ad8232.pdf











AD8232 장착 모듈



4.96US $ 30% OFF|Muscle signal sensor EMG Sensor Ecg module AD8232 ecg measurement pulse heart ecg monitoring sensor kit for Ard







---

첫 등록 : 2023.10.06
